Before you begin...
It is recommended that the following items be available to make this short step-by-step
introduction to the CLICK PLC go smoothly.
CLICK PLC unit
CLICK
Programming Software
C0-PGMSW
Screwdriver
TW-SD-MSL-2
PC Programming Cable
D2-DSCBL
PC with USB port to
Panel Programming
Cable Assembly
EA-MG-PGM-CBL
PC Running
Windows
Hookup Wire
or
CD-ROM or Free download @
http://support.automationdirect.com/
products/clickplcs.html
AC Power Cord
Other 24VDC Power Supply
Example: PSP24-60S
CLICK 24VDC Power Supply
C0-00AC or C0-01AC
PC requires RS-232 port.
Wire Strippers
DN-WS
Not available from ADC.
Not available from ADC.
Based on your CLICK PLC,
One of the cables shown below:
Ethernet Cat5 Cable
CLICK PLC Hardware User Manual, 6th Edition, Rev. G – C0-USER-M
1–4
Chapter 1: Getting Started
