Power Budget Calculation
The following table shows the current consumption required for both the logic side and field
side of the CLICK units.
PLC Current Consumption (mA)
Part Number
Power Budget
24VDC
(logic side)
External
24VDC
(field side)
Basic PLC Units
C0-00DD1-D
120 60
C0-00DD2-D
120 0
C0-00DR-D
120 0
C0-00AR-D
120 0
Standard PLC Units
C0-01DD1-D
140 60
C0-01DD2-D
140 0
C0-01DR-D
140 0
C0-01AR-D
140 0
Analog PLC Units
C0-02DD1-D
140 60
C0-02DD2-D
140 0
C0-02DR-D
140 0
Ethernet Basic PLC Units
C0-10DD1E-D
120 60
C0-10DD2E-D
120 0
C0-10DRE-D
120 0
C0-10ARE-D
120 0
Ethernet Standard PLC Units
C0-11DD1E-D
140 60
C0-11DD2E-D
140 0
C0-11DRE-D
140 0
C0-11ARE-D
140 0
Ethernet Analog PLC Units
C0-12DD1E-D
140 60
C0-12DD2E-D
140 0
C0-12DRE-D
160 0
C0-12ARE-D
160 0
C0-12DD1E-1-D
140 60
C0-12DD2E-1-D
140 0
C0-12DRE-1-D
160 0
C0-12ARE-1-D
160 0
C0-12DD1E-2-D
140 60
C0-12DD2E-2-D
140 0
C0-12DRE-2-D
160 0
C0-12ARE-2-D
140 0
I/O Module Current Consumption (mA)
Part Number
Power Budget
24VDC
(logic side)
External
24VDC
(field side)
Discrete Input Modules
C0-08ND3
30 0
C0-08ND3-1
30 0
C0-16ND3
40 0
C0-08NE3
30 0
C0-16NE3
40 0
C0-08NA
30 0
Discrete Output Modules
C0-08TD1
50 15
C0-08TD2
50 0
C0-16TD1
80 100
C0-16TD2
80 0
C0-08TA
80 0
C0-04TRS
100 0
C0-04TRS-10
120 0
C0-08TR
100 0
C0-08TR-3
90 0
Discrete Combo I/O Modules
C0-16CDD1
80 50
C0-16CDD2
80 0
C0-08CDR
80 0
Specialty Modules
C0-08SIM
50 0
Analog Input Modules
C0-04AD-1
20 65
C0-04AD-2
23 65
C0-04RTD
25 0
C0-04THM
25 0
Analog Output Modules
C0-04DA-1
20 145
C0-04DA-2
20 85
Analog Combo I/O Modules
C0-4AD2DA-1
25 75
C0-4AD2DA-2
20 65
C-more Micro-Graphic Panel (Monochrome only)
All p/n
90 0
CLICK PLC Hardware User Manual, 6th Edition, Rev. G – C0-USER-M
2–24
Chapter 2: Specifications
