General Specifications
General Specifications (all CLICK PLC units)
The following general specifications apply to all CLICK PLC units, optional I/O modules,
and optional power supply products. Please refer to the appropriate I/O temperature derating
charts under both the PLC and I/O module specifications to determine best operating
conditions based on the ambient temperature of your particular application.
General Specifications
Power Input Voltage Range
20–28 VDC
Maximum Power Consumption
5W (No 5V use from communication port)
Maximum Inrush Current
30A (less than 1ms)
Acceptable External Power Drop
Max 10ms
Operating Temperature
Analog units, analog combo I/O modules only: 32°F to 140°F (0°C to
60°C); All other modules: 32°F to 131°F (0°C to 55°C), IEC 60068-2-
14 (Test Nb, Thermal Shock)
Storage Temperature
–4°F to 158°F (–20°C to 70°C)
IEC 60068-2-1 (Test Ab, Cold)
IEC 60068-2-2 (Test Bb, Dry Heat)
IEC 60068-2-14 (Test Na, Thermal Shock)
Ambient Humidity
30% to 95% relative humidity (non–condensing)
Environmental Air
No corrosive gases
The level for the environmental pollution is 2 (UL840)
Vibration
MIL STD 810C, Method 514.2
IEC60068-2-27, Category [f], Procedure[VIII]
JIS C60068-2-27 (Sine wave vibration test)
Shock
MIL STD 810C, Method 516.2
IEC60068-2-27
JIS C60068-2-27, Category [f], Procedure[VIII]
Noise Immunity
<EN61131-2>
EN61000-4-2 (ESD)
EN61000-4-3 (RFI)
EN61000-4-4 (FTB)
EN61000-4-5 (Surge)
EN61000-4-6 (Conducted)
EN61000-4-8 (Power frequency magnetic field immunity)
Comply with NEMA ICS3-304
Impulse noise 1μs, 1000V
RFI: No interference measured at 150MHz and 450MHz (5w/15cm)
Emissions
EN55011:1998 Class A; EN61000-6-4:2007+A1:2011
Agency Approvals
UL508 (File No. E157382, E316037); CE (EN61131-2);
CUL Canadian C22.2
Other
RoHS 2011/65/EU Amendment (EU)2015/863
CLICK PLC Hardware User Manual, 6th Edition, Rev. G – C0-USER-M
2–26
Chapter 2: Specifications
