AutomationDirect CLICK Series User Manual

PLC LED Status Indicators
C0-01DD1-D
RS-485
PORT3
PORT2
PORT1
PWR
RUN
ERR
TX2
RX2
TX1
RX1
TX3
RX3
Standard PLCs
INPUT LEDs (Green)
On Input True
Input FalseOff
OUTPUT LEDs (Red)
On Output True
Output FalseOff
TX & RX LED (Green)
On Comm Port Data Active
No CommunicationOff
POWER LED (Green)
On Power Good
Power FailureOff
RUN LED (Green)
On PLC Run Mode
Initializing
System
PLC Program
Mode
Off
Blink
ERROR LED (RED)
On
Self Diagnostic
Error
Self Diagnostic
Warning
No ErrorOff
Blink
Standard PLC
Basic CPUs
TX & RX LED (Green)
On Comm Port Data Active
No CommunicationOff
INPUT LEDs (Green)
On Input True
Input FalseOff
OUTPUT LEDs (Red)
On Output True
Output FalseOff
POWER LED (Green)
On Power Good
Power FailureOff
RUN LED (Green)
On PLC Run Mode
Initializing
System
PLC Program
Mode
Off
Blink
ERROR LED (RED)
On
Self Diagnostic
Error
Self Diagnostic
Warning
No ErrorOff
Blink
Basic PLC
CLICK PLC Hardware User Manual, 6th Edition, Rev. G – C0-USER-M
2–29
Chapter 2: Specifications
