C0-12DD1E-2-D
C1
X1
X2
X3
X4
C2
Y1
Y2
Y3
Y4
+V
AD1V
AD2V
AD3V
AD4V
ACOM
DA1V
DA2V
ACOM
+
+
24VDC
5 - 27
VDC
+
+
L
24
VDC
L
L
L
Transmitter 0-10V
Transmitter 0-10V
Transmitter 0-10V
Transmitter 0-10V
+
Transmitter P/S
Wiring Diagram
NOTE: Please refer to the Analog I/O Configuration section in Chapter 3 for information on using the analog
I/O.
NOTE: There are no ZIPLink pre-wired PLC connection cables and modules for the Ethernet Analog PLCs
(cannot mix discrete I/O and analog I/O signals in a ZIPLink cable).
WARNING: When using an Ethernet Analog PLC
unit, you must use CLICK programming software
version V2.20 or later.
General Specifications
Current Consumption at 24VDC
140mA
Terminal Block Replacement Part No.
C0-16TB
Weight
5.08 oz
(144g)
C0-12DD1E-2-D – 4 DC Input (Sink/Source)/4 Sinking DC Output;
4 Analog Voltage Input
2 Analog Voltage Output Micro PLC
See Discrete I/O Specifications
Outputs (Y1 – Y4)
See Analog I/O Specifications
Voltage Input
(AD1V – AD4V)
See Analog I/O Specifications
Voltage Output
(DA1V – DA2V)
See Discrete I/O Specifications
Inputs (X1 – X4) High-Speed
