Basic PLC Unit Specifications
C0-00DD1-D – 8 DC Input/6 Sinking DC Output Micro PLC
0
Surrounding Air Te mperature (°C/°F)
32
10
50
20
68
30
85
40
104
50
122
55 °C
131 °F
2
4
6
8
C0-00DD1-D Temperature Derating Chart
0
Inputs
INPUT
X1-X4
Typical
COM
Internal Module Circuitry
Optical Isolator
24 VDC
+
+
INPUT
X5-X8
Typical
COM
Optical Isolator
24 VDC
+
+
C1
C2
To X6-X8
commons
To X2-X4
commons
C0-00DD1-D
+ +
++
24VDC
5 - 27VDC
+
+
L
+
24VD
5 - 27VDC
L
L
L
L
L
Wiring Diagram
General Specifications
Current Consumption at 24VDC
120mA
Terminal Block Replacement Part No.
C0-16TB
Weight
5.0 oz (140g)
Built-in I/O Specifications - Inputs
Inputs per Module
8 (Sink/Source)
Operating Voltage Range
24VDC
Input Voltage Range
21.6–26.4 VDC
Input Current
X1-2: Typ 5mA @ 24VDC
X3-8: Typ 4mA @ 24VDC
Maximum Input Current
X1-2: 6.0 mA @ 26.4 VDC
X3-8: 5.0 mA @ 26.4 VDC
Input Impedance
X1-2: 4.7 kq @ 24VDC
X3-8: 6.8 kq @ 24VDC
ON Voltage Level
X1-2: > 19VDC
X3-8: > 19VDC
OFF Voltage Level
X1-2: < 4VDC
X3-8: < 7VDC
Minimum ON Current
X1-2: 4.5 mA
X3-8: 3.5 mA
Maximum OFF Current
X1-2: 0.1 mA
X3-8: 0.5 mA
OFF to ON Response
X1-2: Typ 5μs Max 20μs
X3-8: Typ 2ms Max 10ms
ON to OFF Response
X1-2: Typ 5μs Max 20μs
X3-8: Typ 3ms Max 10ms
Status Indicators
Logic Side (8 points, green LED)
Commons
2 (4 points/common) Isolated
CLICK PLC Hardware User Manual, 6th Edition, Rev. G – C0-USER-M
2–35
Chapter 2: Specifications
