AutomationDirect CLICK Series User Manual

Error Codes (continued)
PLC Error Codes
Error
Code
Status
Flag*
Error
Name
Category Causes Solutions
354 X512
IO5 CH4
Burnout
Warning
CH4 on the analog I/O module in
I/O5 position senses burnout or
open circuit.
Check the wiring for CH4.
Replace the sensor if it is broken.
360 X602
IO6 Missing
24V
Warning
The analog I/O module in I/
O6 position is missing external
24VDC input.
Apply 24VDC to the analog I/O module.
361 X603
IO6 CH1
Burnout
Warning
CH1 on the analog I/O module in
I/O6 position senses burnout or
open circuit.
Check the wiring for CH1.
Replace the sensor if it is broken.
362 X606
IO6 CH2
Burnout
Warning
CH2 on the analog I/O module in
I/O6 position senses burnout or
open circuit.
Check the wiring for CH2.
Replace the sensor if it is broken.
363 X609
IO6 CH3
Burnout
Warning
CH3 on the analog I/O module in
I/O6 position senses burnout or
open circuit.
Check the wiring for CH3.
Replace the sensor if it is broken.
364 X612
IO6 CH4
Burnout
Warning
CH4 on the analog I/O module in
I/O6 position senses burnout or
open circuit.
Check the wiring for CH4.
Replace the sensor if it is broken.
370 X702
IO7 Missing
24V
Warning
The analog I/O module in I/
O7 position is missing external
24VDC input.
Apply 24VDC to the analog I/O module.
371 X703
IO7 CH1
Burnout
Warning
CH1 on the analog I/O module in
I/O7 position senses burnout or
open circuit.
Check the wiring for CH1.
Replace the sensor if it is broken.
372 X706
IO7 CH2
Burnout
Warning
CH2 on the analog I/O module in
I/O7 position senses burnout or
open circuit.
Check the wiring for CH2.
Replace the sensor if it is broken.
373 X709
IO7 CH3
Burnout
Warning
CH3 on the analog I/O module in
I/O7 position senses burnout or
open circuit.
Check the wiring for CH3.
Replace the sensor if it is broken.
374 X712
IO7 CH4
Burnout
Warning
CH4 on the analog I/O module in
I/O7 position senses burnout or
open circuit.
Check the wiring for CH4.
Replace the sensor if it is broken.
380 X802
IO8 Missing
24V
Warning
The analog I/O module in I/
O8 position is missing external
24VDC input.
Apply 24VDC to the analog I/O module.
381 X803
IO8 CH1
Burnout
Warning
CH1 on the analog I/O module in
I/O8 position senses burnout or
open circuit.
Check the wiring for CH1.
Replace the sensor if it is broken.
382 X806
IO8 CH2
Burnout
Warning
CH2 on the analog I/O module in
I/O8 position senses burnout or
open circuit.
Check the wiring for CH2.
Replace the sensor if it is broken.
383 X809
IO8 CH3
Burnout
Warning
CH3 on the analog I/O module in
I/O8 position senses burnout or
open circuit.
Check the wiring for CH3.
Replace the sensor if it is broken.
384 X812
IO8 CH4
Burnout
Warning
CH4 on the analog I/O module in
I/O8 position senses burnout or
open circuit.
Check the wiring for CH4.
Replace the sensor if it is broken.
* The Status Flags are turned ON when the related errors occur.
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
6–15
Chapter 6: Troubleshooting
