9328900990 Rev L BE1-951 Reporting and Alarm Functions 6-13
In the following load profile recording example (RD-LOG), the CT ratio was set to 120, the current
demand interval (SG-DI) was set to 15, and the load profile logging interval was set to 1. At record 33, the
load profile data reached approximately 90 percent of the final level shown in record 1.
RG Command Example:
>RD-LOG
Record IA IB IC Watts Vars Time Date
1 597A 597A 597A 1.86MW 1.10MVAR 12:36 03/15/04
2 597A 597A 597A 1.86MW 1.10MVAR 12:35 03/15/04
3 597A 597A 597A 1.86MW 1.10MVAR 12:34 03/15/04
4 597A 597A 597A 1.86MW 1.10MVAR 12:33 03/15/04
5 597A 597A 597A 1.86MW 1.10MVAR 12:32 03/15/04
6 597A 597A 597A 1.86MW 1.10MVAR 12:31 03/15/04
7 597A 597A 597A 1.86MW 1.10MVAR 12:30 03/15/04
8 597A 597A 597A 1.86MW 1.10MVAR 12:29 03/15/04
9 597A 597A 597A 1.86MW 1.10MVAR 12:28 03/15/04
10 597A 597A 597A 1.86MW 1.10MVAR 12:27 03/15/04
11 597A 597A 597A 1.86MW 1.10MVAR 12:26 03/15/04
12 595A 595A 595A 1.86MW 1.09MVAR 12:25 03/15/04
13 595A 595A 595A 1.85MW 1.09MVAR 12:24 03/15/04
14 595A 595A 595A 1.85MW 1.09MVAR 12:23 03/15/04
15 595A 595A 595A 1.85MW 1.09MVAR 12:22 03/15/04
16 592A 592A 592A 1.85MW 1.09MVAR 12:21 03/15/04
17 592A 592A 592A 1.85MW 1.09MVAR 12:20 03/15/04
18 592A 592A 592A 1.84MW 1.09MVAR 12:19 03/15/04
19 590A 590A 590A 1.84MW 1.09MVAR 12:18 03/15/04
20 590A 590A 590A 1.84MW 1.08MVAR 12:17 03/15/04
21 588A 588A 588A 1.83MW 1.08MVAR 12:16 03/15/04
22 585A 585A 585A 1.83MW 1.08MVAR 12:15 03/15/04
23 585A 585A 585A 1.82MW 1.07MVAR 12:14 03/15/04
24 583A 583A 583A 1.81MW 1.07MVAR 12:13 03/15/04
25 578A 578A 578A 1.80MW 1.06MVAR 12:12 03/15/04
26 576A 576A 576A 1.79MW 1.06MVAR 12:11 03/15/04
27 571A 571A 571A 1.78MW 1.05MVAR 12:10 03/15/04
28 568A 568A 568A 1.77MW 1.04MVAR 12:09 03/15/04
29 564A 564A 564A 1.75MW 1.03MVAR 12:08 03/15/04
30 556A 556A 556A 1.73MW 1.02MVAR 12:07 03/15/04
31 549A 549A 549A 1.71MW 1.01MVAR 12:06 03/15/04
32 542A 542A 542A 1.69MW 994KVAR 12:05 03/15/04
33 532A 532A 532A 1.66MW 976KVAR 12:04 03/15/04
34 520A 520A 520A 1.62MW 956KVAR 12:03 03/15/04
35 508A 508A 508A 1.58MW 932KVAR 12:02 03/15/04
36 494A 494A 494A 1.54MW 904KVAR 12:01 03/15/04
37 475A 475A 475A 1.48MW 872KVAR 12:00 03/15/04
38 456A 456A 456A 1.42MW 834KVAR 11:59 03/15/04
39 432A 432A 432A 1.35MW 790KVAR 11:58 03/15/04
VT MONITOR FUNCTIONS
The VT Monitor reporting function allows the user to enable or disable Fuse Loss Block Logic. The Block
Voltage Control box can be checked (enabled) or unchecked (disabled) for the 51/27 elements. Likewise,
Block Phase, Block 3V0, and Block V2 can each be independently checked (enabled) or unchecked
(disabled) for the 27 and 59 elements. The default value for all of these logic functions is enabled.
Setting Fuse Loss Block Logic
Fuse Loss Block Logic settings can be made using BESTCOMS.
Figure 6-4 illustrates the BESTCOMS
screen used to select these reporting settings. To open the screen shown in
Figure 6-4, select Reporting
and Alarms, from the S
creens pull-down menu. Then select the VT Monitor tab. Alternately; settings may
be made using the SP-60FL ASCII command.
