8-46 BE1-951 Application 9328900990 Rev L
BACKUP Logic Settings and Equations
SL-N=BACKUP
SL-50TP=1,0; SL-50TN=1,0; SL-50TQ=1,0
SL-150TP=1,0; SL-150TN=1,0; SL-150TQ=1,0
SL-51P=1,0
SL-51N=1,0
SL-51Q=1,0
SL-151N=0,0
SL-24=0,0
SL-25=0,0
SL-27P=0,0; SL-27X=0,0
SL-47=0,0
SL-59P=0,0; SL-59X=0,0
SL-159X=0,0
SL-81=0,0
SL-181=0,0
SL-281=0,0
SL-381=0,0
SL-481=0,0
SL-581=0,0
SL-32=0,0
SL-62=0,0,0
SL-162=0,0,0
SL-79=0,0,0,0,0
SL-86=0,0,0
SL-186=0,0,0
SL-BF=1,VO10,VO15
SL-GROUP=2,/IN2,0,0,0,0
SL-43=0
SL-143=0
SL-243=0
SL-343=2
SL-101=1
SL-VOA=0
SL-VO1=BFPU+VO8+101T
SL-VO2=101C
SL-VO3=/IN2
SL-VO4=VO9
SL-VO5=BFT
SL-VO6=0
SL-VO7=0
SL-VO8=51PT+51NT+51QT
SL-VO9=50TPT+50TNT+50TQT
SL-VO10=VO11+150TPPU*IN3+150TNPU*IN3+150TQPU*IN3
SL-VO11=50TPT+50TNT+50TQT+51PT+51NT+51QT
SL-VO12=50TPPU+50TNPU+50TQPU+51PPU+51NPU+51QPU
SL-VO13=0
SL-VO14=0
SL-VO15=343+/IN4
MISCELLANEOUS LOGIC EXPRESSIONS
Several logic expression settings are classified as miscellaneous. That is, they are not included in the
BESTlogic settings and are not set through the ASCII command interface using the SL (Set Logic)
commands. Several of the Reporting and Alarm Functions provided in the relay require programmable
logic expressions to determine their functionality. These settings are included with the setup parameters
associated with each function.
Table 8-25 cross-references the manual sections and setting commands
associated with these non-BESTlogic logic settings.
Each of the pre-programmed logic schemes is designed to be compatible with the factory default logic
expression settings for these Reporting and Alarm functions. However, when copying a pre-programmed
scheme into your logic settings for modification, it is important to recognize that settings will not be copied
