9328900990 Rev L BE1-951 General Information 1-7
Figure 1-1. Style Chart
OPERATIONAL SPECIFICATIONS
BE1-951 relays have the following features and capabilities.
Metered Current Values and Accuracy
Current Range
5A: 0.5 to 15
1A: 0.1 to 3.0
Accuracy: ±1% of reading, ±1 least significant digit at 25°C
Temperature Dependence: ≤ ±0.02% per °C
Metered Voltage Values and Accuracy
Voltage Range
3 wire: 0 to 300 V
L-L
4 wire: 0 to 300 V
L-L
Accuracy (10 to 75 hertz)
50 V to 300 V: ±0.5% of reading, ±1 least significant digit at 25°C
Temperature Dependence: ≤ ±0.02% per °C
Metered Frequency Values and Accuracy
Frequency Range: 10 to 75 hertz
Accuracy: ±0.01 hertz, ±1 least significant digit at 25°C
Sensing Input
3-wire: Phase A - B
4-wire: Phase A - Neutral
Minimum Frequency Tracking Voltage: 10 V RMS
