12-22 BE1-951 Installation 9328900990 Rev L
POWER SYSTEM APPLICATIONS
Figures 12-23 through 12-35 are examples of the applications that can be served by the Basler BE1-951
directional overcurrent numeric relay system. Many of these applications can be used in concert with
other Basler numeric systems such as the BE1-851 Utility Multifunction Relay, the BE1-CDS220/240
Current Differential Protection Systems, or the BE1-GPS100 Generator Protection System.
Figure 12-23. Three-Phase Voltage Sensing, Alternate VTP Input
