9328900990 Rev L BE1-951 Application 8-11
Function Purpose
BESTlogic
Expression
Mode
Setting
181 N/A 0 0 (disabled)
281 N/A 0 0 (disabled)
381 N/A 0 0 (disabled)
481 N/A 0 0 (disabled)
581 N/A 0 0 (disabled)
32 N/A 0 0 (disabled)
Reclose Initiate Logic: Initiate when Reclose Initiate Expression is
TRUE.
VO8
Breaker Status Logic: Closed breaker is indicated when IN1 is
de-energized.
/IN1
Wait Logic: Stop recloser timing when timing for a fault trip.
TRUE when protection picked up expression is TRUE.
VO12
79
Block/Drive to Lockout Logic: Drive recloser to lockout when
recloser drive to lockout expression is TRUE.
VO9
1 (Power Up
to Lockout)
BF N/A 0 0 (disabled)
62 N/A 0 0 (disabled)
162 N/A 0 0 (disabled)
86 N/A 0 0 (disabled)
186 N/A 0 0 (disabled)
Input 0 Logic: No manual selection logic is used. 0
Input 1 Logic: No manual selection logic is used. 0
Input 2 Logic: No manual selection logic is used. 0
Input 3 Logic: No manual selection logic is used. 0
GROUP
Auto/Manual Logic: Set to 1 (/0) to enable automatic selection.
No manual selection is used.
/0
1 (Discrete
Input
Selection)
Table 8-7. OC-W-79 Virtual Switch Logic
State Labels
Switch Purpose Mode Label
True False
43 N/A 0 (Disable) SWITCH_43 CLOSED OPEN
143 N/A 0 (Disable) SWITCH_143 CLOSED OPEN
243 N/A 0 (Disable) SWITCH_243 CLOSED OPEN
343 N/A 0 (Disable) SWITCH_343 CLOSED OPEN
101 N/A 0 (Disable) N/A N/A N/A
To Next Page
