12-18 BE1-951 Installation 9328900990 Rev L
POWER
SUPPLY 1
IN IN
24
ININ
3
CIRCUIT
MONITOR
A6
A7 B2
B1 +
-
+B3
-
B4 B6 -
B5
+
-
B8
+
B7
BE1-951
CONTROL
POWER
POWER
CONTROL
RECLOSE
INITIATE SEQ ENABLE
GROUND NEG
52b
RECLOSER
DRIVE TO
LOCKOUT
C1
C2
OUT
12
OUT
C4
C3 C5
C6
OUT
34
OUT
C8
C7 C9
C10
OUT
5A
OUT
C12
C11
52 TRIP
COIL COIL
52 CLOSE NOT
USED ALARM
MINOR MAJOR
ALARM ALARM
D10
D9
2
2
2
06-14-06
D2848-42
1
1
1
Connections shown are for use with the pre-programmed logic scheme OC-W-79. This scheme provides overcurrent protection with reclosing capabilities. All inputs and outputs are fully programmable using BESTlogic.
Additional output terminal connections D19 and D20 with test plug are available in S1 Double-Ended Case only.
Figure 12-18. Typical External DC Connections
