3

Click the Install button of Color Calibration Man-

agement Console.

4

Click the Next button.

5

After reading the license agreement, select I accept

the terms of the license agreement and click the

Next button.

Installation Procedure

iPF8400S

User's Guide

Color Management Color Calibration Management Console (Windows)

742
