Acquiring Color Measurement Data

1

Open the Color Measurement sheet.

2

Select the printer you want to measure the color

chart on from the Printer list.

3

Click the Color Measure button.

iPF8400S

Acquiring Color Measurement Data For Any Color Chart

User's Guide

Color Management Color Calibration Management Console (Windows)

761
