6

Pull up the Printhead Fixer Cover to open it com-

pletely.

7

Remove the Printhead and press the OK button.

Note

• Dispose of the used Printhead in accordance with local regulations.

8

Holding the new Printhead by the grips (a), remove it from

the pouch.

iPF8400S

Replacing the Printhead

User's Guide

Maintenance and Consumables Printheads

823
