Important
•
Do not touch the Linear Scale (a), Carriage Shaft (b),
or Fixed Blade (c). This may stain your hands and
damage the printer.
7
Holding the new Shaft Cleaner by the grips (a), at-
tach it to the Carriage.
Note
• Be sure to put the used Shaft Cleaner in the small box before putting it in the larger box with the used Mainte-
nance Cartridge for disposal.
8
Close the Top Cover.
The Carriage moves back into position.
iPF8400S
Replacing the Maintenance Cartridge
User's Guide
Maintenance and Consumables Maintenance Cartridge
837
