xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
120
Format
create cpu access_profile profile_id <value 1-5> [ethernet {vlan | source_mac <macmask
000000000000-ffffffffffff> | destination_mac <macmask 000000000000-ffffffffffff> | 802.1p |
ethernet_type}(1) | ip {vlan | source_ip_mask <netmask> | destination_ip_mask <netmask> |
dscp | [icmp {type | code} | igmp {type} | tcp {src_port_mask <hex 0x0-0xffff> | dst_port_mask
<hex 0x0-0xffff> | flag_mask [all | {urg | ack | psh | rst | syn | fin}]} | udp {src_port_mask <hex
0x0-0xffff> | dst_port_mask <hex 0x0-0xffff>} | protocol_id_mask <hex 0x0-0xff>
{user_define_mask <hex 0x0-0xffffffff>}]}(1) | packet_content_mask {offset_0-15 <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_16-31 <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_32-47 <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_48-63 <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_64-79 <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>}(1) | ipv6 {class | flowlabel |
source_ipv6_mask <ipv6mask> | destination_ipv6_mask <ipv6mask>}(1)]
Parameters
<value 1-5> - Specify a value between 1 and 5.
ethernet - Specify an Ethernet CPU access control list rule.
vlan - Specify a VLAN mask.
source_mac - Specify the source MAC mask.
<macmask000000000000-ffffffffffff> - Specify the source MAC mask.
destination_mac - Specify the destination MAC mask.
<macmask 000000000000-ffffffffffff> - Specify the destination MAC mask.
802.1p - Specify the 802.1p priority tag mask.
ethernet_type - Specify the Ethernet type mask.
ip - Specify an IP CPU access control list rule.
vlan - Specify a VLAN mask.
source_ip_mask - Specify an IP source submask.
<netmask> - Specify an IP source submask.
destination_ip_mask - Specify an IP destination submask.
<netmask> - Specify an IP destination submask.
dscp - Specify the DSCP mask.
icmp - Specify that the rule applies to ICMP traffic.
type - (Optional) Specify the ICMP packet type.
code - (Optional) Specify the ICMP code.
igmp - Specify that the rule applies to IGMP traffic.
type - (Optional) Specify the IGMP packet type.
tcp - Specify that the rule applies to TCP traffic.
src_port_mask - (Optional) Specify the TCP source port mask.
<hex 0x0-0xffff> - Specify the TCP source port mask.
dst_port_mask - (Optional) Specify the TCP destination port mask.
<hex 0x0-0xffff> - Specify the TCP destination port mask.
flag_mask - (Optional) Specify the TCP flag field mask.
all – Specify to check all paramenters below.
urg - (Optional) Specify Urgent Pointer field significant.
ack - (Optional) Specify Acknowledgment field significant.
psh - (Optional) Specify Push Function.
rst - (Optional) Specify to reset the connection.
syn - (Optional) Specify to synchronize sequence numbers.
fin - (Optional) No more data from sender.
udp - Specify that the rule applies to UDP traffic.
