xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
122
DGS-3420-28SC:admin#create cpu access_profile profile_id 2 ip source_ip_mask
255.255.255.255
Command: create cpu access_profile profile_id 2 ip source_ip_mask 255.255.255.25
5
Success.
DGS-3420-28SC:admin#
5-10 config cpu access_profile profile_id
Description
This command is used to configure CPU access list entries.
Format
config cpu access_profile profile_id <value 1-5> [add access_id [auto_assign | <value 1-100>]
[ethernet {[vlan <vlan_name 32> | vlan_id <vlanid 1-4094>] | source_mac <macaddr> |
destination_mac <macaddr> | 802.1p <value 0-7> | ethernet_type <hex 0x0-0xffff>} | ip {[vlan
<vlan_name 32> | vlan_id <vlanid 1-4094>] | source_ip <ipaddr> | destination_ip <ipaddr> |
dscp <value 0-63> | [icmp {type <value 0-255> | code <value 0-255>} | igmp {type <value 0-255>}
| tcp {src_port <value 0-65535> | dst_port <value 0-65535> | flag [all | {urg | ack | psh | rst | syn |
fin}]} | udp {src_port <value 0-65535> | dst_port <value 0-65535>} | protocol_id <value 0-255>
{user_define <hex 0x0-0xffffffff>}]} | packet_content {offset_0-15 <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_16-31 <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_32-47 <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_48-63 <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_64-79 <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>} | ipv6 {class <value 0-255> | flowlabel <hex
0x0-0xfffff> | source_ipv6 <ipv6addr> | destination_ipv6 <ipv6addr>}] port [<portlist> | all]
[permit | deny] {time_range <range_name 32>} | delete access_id <value 1-100>]
Parameters
<value 1-5> - Specify the index of the CPU access list profile.
add access_id - Specify the index of an access list entry to add. The range of this value is 1 to 100.
auto_assign - Specify to automatically assign the access ID.
<value 1-100> - Specify an access ID between 1 and 100.
ethernet - Specify an Ethernet CPU access control list rule.
vlan - Specify the VLAN name.
<vlan_name 32> -Specify the VLAN name. The maximum length is 32 characters.
vlanid - Specify the VLAN ID.
<vlanid 1-4094> - Specify the VLAN ID between 1 and 4094.
source_mac - Specify the source MAC address.
<macaddr> - Specify the source MAC address.
destination_mac - Specify the destination MAC address.
<macaddr> - Specify the destination MAC address.
802.1p - Specify the value of the 802.1p priority tag.
