xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
123
<value 0-7> - Specify the value of the 802.1p priority tag. The priority tag ranges from 1 to 7.
ethernet_type - Specify the Ethernet type.
<hex 0x0-0xffff> - Specify the Ethernet type.
ip - Specify an IP access control list rule.
vlan - Specify the VLAN name.
<vlan_name 32> -Specify the VLAN name. The maximum length is 32 characters.
vlanid - Specify the VLAN ID.
<vlanid 1-4094> - Specify the VLAN ID between 1 and 4094.
source_ip - Specify an IP source address.
<ipaddr> - Specify an IP source address.
destination_ip - Specify an IP destination address.
<ipaddr> - Specify an IP destination address.
dscp - Specify the value of DSCP.
<value 0-63> - Specify the value of DSCP. The DSCP value ranges from 0 to 63.
icmp - Specify the ICMP.
type - (Optional) Specify that the rule will apply to the ICMP Type traffic value.
<value 0-255> - Specify the value between 0 and 255.
code - (Optional) Specify that the rule will apply to the ICMP Code traffic value.
<value 0-255> - Specify the value between 0 and 255.
igmp - Specify the IGMP.
type - (Optional) Specify that the rule will apply to the IGMP Type traffic value.
<value 0-255> - Specify the value between 0 and 255.
tcp - Specify TCP.
src_port - (Optional) Specify that the rule will apply to a range of TCP source ports.
<value 0-65535> - Specify the value between 0 and 65535.
dst_port - (Optional) Specify that the rule will apply to a range of TCP destination ports.
<value 0-65535> - Specify the value between 0 and 65535.
flag - Specify the TCP flag field value.
all – Specify to check all paramenters below.
urg - (Optional) Specify Urgent Pointer field significant.
ack - (Optional) Specify Acknowledgment field significant.
psh - (Optional) Specify Push Function.
rst - (Optional) Specify to reset the connection.
syn - (Optional) Specify to synchronize sequence numbers.
fin - (Optional) No more data from sender.
udp - Specify UDP.
src_port - (Optional) Specify the UDP source port range.
<value 0-65535> - Specify the value between 0 and 65535.
dst_port - (Optional) Specify the UDP destination port range.
<value 0-65535> - Specify the value between 0 and 65535.
protocol_id - Specify that the rule will apply to the value of IP protocol ID traffic.
<value 0-255> - Specify the value between 0 and 255.
user_define - (Optional) Specify that the rule will apply to the IP protocol ID and that the mask
options behind the IP header, which has a length of 4 bytes.
<hex 0x0-0xffffffff> - Specify that the rule will apply to the IP protocol ID and that the mask
options behind the IP header , which has a length of 4 bytes.
packet_content - Specifies that the access control list rule will be set to packet content.
offset_0-15 - Specify the mask for packet bytes 0-15.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 0-3.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 4-7.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 8-11.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 12-15.
offset_16-31 - Specify the mask for packet bytes 16-31.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 16-19.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 20-23.
