xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
124
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 24-27.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 28-31.
offset_32-47 - Specify the mask for packet bytes 32-47
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 32-35.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 36-39.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 40-43.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 44-47.
offset_48-63 - Specify the mask for packet bytes 48-63.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 48-51.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 52-55.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 56-59.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 60-63.
offset_64-79 - Specify the mask for packet bytes 64-79.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 64-67.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 68-71.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 72-75.
<hex 0x0-0xffffffff> - Specify the mask for packet bytes 76-79.
ipv6 - Specify that the rule applies to IPv6 fields.
class - Specify the value of the IPv6 class.
<value 0-255> - Specify the value between 0 and 255.
flowlabel - Specify the value of the IPv6 flow label.
<hex 0x0-0xfffff> - Specify the value of the IPv6 flow label.
source_ipv6 - Specify the value of the IPv6 source address.
<ipv6addr> - Specify the value of the IPv6 source address.
destination_ipv6 - Specify the value of the IPv6 destination address.
<ipv6addr> - Specify the value of the IPv6 destination address.
port - Specify the port number to configure.
<portlist> - Specify a list of ports.
all - Specify to configure all ports.
permit - Specify the packets that match the access profile are permitted by the switch.
deny - Specify the packets that match the access profile are filtered by the switch.
time_range - (Optional) Specify the name of this time range entry.
<range_name 32> - Specify the name of this time range entry. The maximum length is 32
characters.
delete access_id - Specify to delete the access ID.
<value 1-100> - Specify the value between 1 and 100.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure access list entry:
DGS-3420-28SC:admin#config cpu access_profile profile_id 1 add access_id 1 ethernet
vlan default port 1-3 deny
Command: config cpu access_profile profile_id 1 add access_id 1 ethernet vlan
default port 1-3 deny
Success.
DGS-3420-28SC:admin#
