E-GENIUS

113

Field Name

Action/Definition

If the code is not read during the reading phase, the No Read message is

produced.

NOTE: If there are multiple barcodes within the

barcode readers read area during a trigger cycle,

the first barcode decoded will be the data

transmitted to the host.

 Standard Multi Label: In Multi Label mode the barcodes selected (up to 10), will

all be read in the same reading phase. If the reading phase terminates before all

the codes are read, a Global No Read message will be produced, unless it is

disabled, in which case a Local No Read will be produced.

NOTE: In case of Multi Label, the codes will be

distinguished EITHER by their symbology, OR

by their contents. If two (or more) codes share

the same symbology and content, the barcode

reader will perceive them as a unique code.

 Logical Combination: In Logical Combination mode the codes of the groups

defined by the Logical Combination Rule are read in the same reading phase.

 Code Collection: In Code Collection mode expected codes are collected within

a single reading phase in the order in which they are read. The No Read

message is produced only if none of the codes are read. Up to 50 codes can be

collected.

3. When you have finished making changes, click Update to save or click Reset to revert to

the previously saved values.
