11 -Fuel injection - ignition system
The electrical components of the fuel injection-ignition system are listed below: indicated reference number refers to the
diagram in Sect. 6 - 1,
Key to wiring diagram:
Key to fuel injection–ignition system diagram
3) Horizontal cylinder spark plug
4) Vertical cylinder spark plug
6) Starter contactor
7) Battery
8) Main fuse
15) Fuel tank
18) Self-diagnosis/DDA
19) Horizontal cylinder coil
20) Vertical cylinder coil.
23) Horizontal cylinder injector
24) Vertical cylinder injector
25) Throttle position sensor
26) Timing/rpm sensor
29) Side stand
32) Oil pressure switch
34) ECU
35) Fuses
40) Air temperature sensor
47) Stepper motor
