Ducati Monster 796 - Removal of the Seat Release Mechanism

Tail light-number plate holder and locks
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_7_18.56.1.html[11/12/2015 18:40:38]
Refit the tail light - number plate holder assembly to the rear subframe, inserting it as shown in the photo.
Fit and tighten the four screws (25) to a tightening torque of 22 Nm ±10% (Sect. 3 - 3, Frame torque settings).
Connect the main wiring connector (A) to the main wiring harness (Sect. 6 - 1, Routing of wiring on frame).
Operations Section reference
Refit the exhaust valve motor 8 - 8, Refitting the exhaust system
Refit the tool tray 5 - 3,
Refitting the tool tray
Refit the seat 5 - 3,
Refitting the seat
Removal of the seat release mechanism
Remove the tail light - number plate holder assembly from the rear subframe and the plate (24) as described in the
