Ducati Monster 796 - Cooling System; Front Suspension; Front Wheel; Hydraulic Brakes

Technical specifications
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_3_1A.9.1.html[11/12/2015 18:40:10]
Selector fork-to-gear clearance 0.070 to 0.285 mm 0.4 mm
Cooling system
Reference Technical specifications
Type
Air-cooled: heat dispersion through the
extensive finning on the two cylinder
barrel/head assemblies
Front wheel
Reference Standard value Service limit
Minimum tread depth
In the most worn part 2 mm
Tyre pressure
Cold 2.25 bar
Wheel shaft runout
On 100 mm 0.05 mm
Wheel rim runout
Radial 1 mm (0.04 in.)
Lateral 0.5 mm (0.02 in.)
Air gap Range 1.3 mm to 1.9 mm
Front suspension
Reference Technical specifications
Type
SHOWA: 43 mm Ø upside-down hydraulic fork,
non-adjustable
Fork travel 120 mm
Fork
Not adjustable.
Oil charge per leg
500 cm
3
(per leg)
Rear wheel
Reference Standard value Service limit
Minimum tread depth
In the most worn part 2 mm
Tyre pressure
Cold 2.50 bar
Swingarm pivot runout
On 100 mm 0.2 mm
Wheel rim runout
Radial 1 mm (0.04 in.)
Lateral 0.5 mm (0.02 in.)
Drive chain
Make
Type
REGINA
525 ZR PK
Dimensions 5/8“ x 1/4“
No. of links 108 open
Rear suspension
Reference Technical specifications
Type
SACHS: progressive monoshock with
adjustable rebound, compression and
spring preload.
Shock absorber
Stroke 59.5 mm
Hydraulic damping standard setting.
Turn the adjusters fully clockwise until
they stop, then turn them anticlockwise
Rebound: 8 clicks
Spring preload 15 mm
Standard preloaded spring length 150±1 mm
Wheel travel 148 mm
Hydraulic brakes
Reference Standard value Service limit
FRONT
Brake disc
Type Drilled dual disc
