3 -Torque settings
Frame torque settings
Part Thread/pitch (mm) Nm ±10%
Tolerance
Note
Headlight fairing
Screw securing Plexiglas to headlight fairing M4x0.7 0.2 Wellnut fixing
Screw securing headlight fairing bracket to
headlight support
Lower screws initial tightening
Upper screws final tightening
Lower screws final tightening
M6x1
1.5
8
8
Screw securing headlight fairing to bracket M5x0.8 5
Rear-view mirror screw M8x1.25 25
Side stand
Nut securing side stand rotation pivot screw M10x1.25 20
Screw securing side stand bracket to crankcase M10x1.5 36 LOCK 2
Stand sensor screw M6x1 5 LOCK 2
Front sprocket
Front sprocket retaining screw M25x1.5
186
*
Front sprocket cover screw M6x1 6
Lights and reflectors
Screw securing headlight to support M5x0.8 5 LOCK 2
Screw securing headlight support to bottom
yoke
M6x1 10
Screw securing front turn indicator to headlight
support
M5x0.8 3 LOCK 2
Screw securing headlight to support M5x0.8 3
Instruments
Screw securing instrument panel to support 3
Instrument panel cover retaining screw M4x0.7 1.5
Front Fork
Steering shaft nut M35x1
30
*
GREASE B
Screw securing front brake hose guide to
bottom yoke
M6x1 8 LOCK 2
Steering limit lock nut M8x1.25 18 LOCK 2 (apply Loctite
to nut thread only)
Screw securing steering head to pivot M8x1.25
24
*
GREASE B
Bottom yoke to fork retaining screws (RH + LH) M8x1.25
22
*
GREASE B
In the sequence 1-2-
1
Fork bottom end retaining screws (RH + LH) M8x1.25
18
*
GREASE B
In the sequence 1-2-
