Removal of the valve covers
Operations Section reference
Remove the seat 5 - 3, Removal of the seat
Remove the tank covers 5 - 2,
Removal of the fuel tank
fairings
Remove the fuel tank 8 - 2,
Removal of the fuel tank
Remove the oil cooler from the
frame
9 - 2.2,
Removal of the oil cooler
In the ABS version, the ABS pipe support (A) is fixed to the cover (8) of the exhaust-side vertical cylinder head. Loosen
the screws (B) and remove the support.
Loosen the retaining screws (7) of the valve covers (8) and remove the covers with relative O-rings (9).
