Torque settings
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_3_3.12.1.html[11/12/2015 18:40:11]
Screw securing cable guide to LH side of
crankcase
M6x1 10
Clamp securing hoses to airbox 1.1
Cable guide to LH side of crankcase fastener M5x0.8 5
EVAP system canister filter
Screws securing temperature sensor to intake
hose
M3x0.5 0.4 LOCK 9
Clamp securing hose to throttle body 1.5
Clamp securing throttle body to intake manifold 1.5
Stepper tube clamp tightening 10
Canister fixing to LH air cowling M6x1 8 For USA version only.
Fairings
Lower screw fixing RH and LH deflector to
frame
M5x0.8 5
Screw fixing RH and LH deflector to central air
cowling
M5x0.8 5
Upper screw fixing RH and LH deflector to
frame
M5x0.8 5
Screw securing voltage regulator to RH air
cowling
M6x1 8
Generator cover retaining screw M5x0.8 5
* dynamic safety-critical point; tightening torque must be within Nm ±5%.
Note
For product specifications and symbols, refer to “Product specifications” (Sect. 1 - 2).
Engine torque settings
Part Thread/pitch (mm) Nm Min. Max. Note
Camshaft timing belt pulley nut M15x1 71 64 78 GREASE A
Cylinder head nut:
Snug torque
Preload torque
Tightening torque
M10x1.5
15
30
48
13
28
46
17
32
50
Apply GREASE C to
the underside and the
thread of the stud
screw
Intake flange stud M8x1.25 15 13 17 LOCK 2 or TB1324
Intake manifold nut M8x1.25 23 20 26
Exhaust flange stud M8x1.25 15 13 17 LOCK 2 or TB1324
Timing hole cover M8x1.25 10 9 11
Vertical cylinder oil temperature sensor M8x1.5 9 8.5 9.5
Cylinder head service screw (aluminium) M6x1 3 2 3 LOCK 5
Intake/exhaust valve cover screws M6x1 10 9 11
Valve cover screws M6x1 10 9 11 LOCK 2
Timing belt cover screw M6x1 10 9 11 LOCK 2 or TB1324
Timing belt cover screw M6x1 10 9 11 LOCK 2 or TB1324
Pulley flange retaining screw M6x1 10 9 11
Canister plug screw M6x1 5 4 6
Pick-up filter housing plug M32x1.5 42 38 46
Oil pick-up filter M22x1.5 42 38 46
Canister nipple (USA version) M6x1 5 4 6
MAP sensor coupling screw M5x0.8 5 4 6
Oil cartridge nipple M16x1.5 42 38 46 LOCK 2 or TB1324
Oil cartridge M16x1.5 11 10 12 Engine oil on the
