Torque settings
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_3_3.12.1.html[11/12/2015 18:40:11]
gasket
Oil pump intake service hole plug M15x1 25 22 28 LOCK 5
Oil cooler nipple M14x1.5 32 29 35 LOCK 5
Oil drain plug with magnet M12x1.5 20 18 22 TB1215
Blow-by hole service plug M12x1 15 13 17 LOCK 5
Main oil way plug M10x1.5 15 13 17 LOCK 5 or TB1375B
Clutch cover inner oilway screw M10x1.5 15 13 17 LOCK 5
Cylinder barrel/head stud M10x1.5 30 28 32 LOCK 2 or TB1324
Neutral warning light switch M10x1.5 10 9 11
Taper blanking plug for service hole M10x1 20 18 22 LOCK 5
Oil pump adapter screw M10x1 LOCK 5
Crankcase screw
Initial tightening
Final tightening
M8x1.25
19
25
17
22
21
28
Apply GREASE B to
thread
Gear stop lever screw M8x1.25 18 16 20 LOCK 2 or TB1324
Crankcase screw M6x1 10 9 11
Blow-by valve screw M6x1 10 9 11
Radial pick-up screw M6x1 10 9 11
Clutch side primary bearing retaining plate
screw
M6x1 10 9 11 LOCK 2 or TB1324
Chain side secondary bearing plate retaining
screw
M6x1 10 9 11 LOCK 2 or TB1324
Idler gear shaft retaining screw M6x1 10 9 11 LOCK 2 or TB1324
Adler clutch oil calibration screw M6 6 5 7
Starter motor mounting screw M6x1 10 9 11 LOCK 2
Outer starter motor mounting screw M6x1 10 9 11 LOCK 2
Flywheel nut M24x1 270 256 284 LOCK 5
Primary drive gear nut M22x1 190 171 209 GREASE B
Steel/aluminium crankshaft blanking cap M20x1 15 13.5 16.5 LOCK 5
Connecting rod screw
Tighten at 50 rpm
2 second pause, then back off through
360° at 30 rpm
Tighten at 30 rpm
Tighten at 10 rpm
Tighten at 14 rpm
Torque check
M10x1
35
20
35
65º ±1º
70÷103
Apply GREASE B to
thread
Crankshaft grub screw M8x1.25 13 11 15 LOCK 5
Drilled crankshaft grub screw M8x1.25 13 11 15 LOCK 5
Selector drum locating screw M16x1.5 30 27 33
Selector claw screw M8x1.25 36 34 38 LOCK 2 or TB1324
Selector claw locator nut M6x1 10 9 11
Selector claw screw M6x1 16 15 17 LOCK 2 or TB1324
Timing belt driveshaft pulley retaining nut M15x1 71 64 78 GREASE A
Timing belt driveshaft gear nut M14x1 55 50 60 GREASE A
Tensioner pulley retaining screw M8x1.25 26 23 29
Idler pulley retaining screw M8x1 20 18 22 LOCK 2 or TB1324
Plastic cover screw M6x1 10 9 11
Wet clutch centre nut M25x1.5 190 180 200 GREASE B
Oil filler plug M20x2.5 FULLY HOME
Soundproofing gasket fixing screw M14x1.5 24 22 26 LOCK 5
Pick-up sensor inspection screw M12x1 15 13 17 LOCK 2 or TB1324
Oil way blanking plug M10x1 20 18 22 LOCK 5
Oil pressure sensor M10x1 19 17 21
Wet clutch cover screw M6x1 10 9 11
Wet clutch spring screw M6x1 10 9 11
Spark plug M12x1.25 20 18 22
Generator cover screw M6x1 13.5 12.5 14.5
Generator stator retaining screw M6x1 10 9 11 LOCK 2 or TB1324
Alternator rotor/flywheel screw M6x1 13 11 15 LOCK 5
