Crankcase assembly: external components
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_9_9A.78.1.html[11/12/2015 18:40:52]
34 Pick-up sensor
35 Grub screw
36 Bush
37 Sealing washer
38 Ball
39 Spring
Spare parts catalogue
796
TIMING SYSTEM
796
FILTERS AND OIL PUMP
796
CRANKCASE HALVES
796
ELECTRIC STARTING AND IGNITION
796
GEARCHANGE CONTROL
796 ABS
TIMING SYSTEM
796 ABS
FILTERS AND OIL PUMP
796 ABS
CRANKCASE HALVES
796 ABS
ELECTRIC STARTING AND IGNITION
796 ABS
GEARCHANGE CONTROL
Important
Bold reference numbers in this section identify parts not shown in the figures alongside the text, but which can be found in
the exploded view diagram.
Removing outer components
Operations Section reference
Remove the engine from the frame 9 - 1, Removal of the engine
Remove the clutch cover 9 - 6.2,
Removal of the clutch cover
Remove the complete clutch
assembly
9 - 6.1,
Removal of the APTC clutch
Remove the oil pump 9 - 2.1,
Removal of the oil pump
Remove the generator cover 9 - 8,
Removal of the generator
cover
Remove the engine starting system 6 - 3,
Electric starting system
Remove the side timing belt covers 9 - 4.2,
Removal of the timing belt
covers
Remove the timing belts 9 - 4.2,
Removal of the timing
system assembly
Remove the cylinder heads 9 - 4.4,
Removal of the cylinder
head assembly
Remove the cylinder barrel/piston
assemblies
9 - 5,
Removal of the
cylinder/piston assembly
Note
The following removal operations are required in order to renew and/or clean the crankcase halves. If the original
crankcase halves are to be reused, then the removal of these components is not essential.
Unscrew the screw (30) and remove the oil breather valve (10) with the O-rings (11). Check the condition of O-rings (11)
and renew them if necessary.
