05 - Impianto elettrico
1 - Headlight fairing - rear-view mirrors 3
Removal of the rear-view mirrors 4
Refitting the rear-view mirrors 4
Removal of the headlight fairing 5
Refit the headlight fairing 8
2 - Fairings 9
Removal of the fuel tank fairings 10
Refitting the fuel tank fairings 12
3 - Seat 16
Removal of the seat 17
Refitting the seat 18
Removal of the tool tray 18
Refitting the tool tray 19
4 - Front and rear mudguard 20
Removal of the front mudguard 21
Refitting the front mudguard 23
Removing the rear mudguard 25
Refitting the rear mudguard 25
