Technical specifications
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_3_1A.9.1.html[11/12/2015 18:40:10]
Intake Opening 18° B.T.D.C.
Closing 60° A.B.D.C.
Exhaust Opening 53° B.B.D.C.
Closing 23° A.T.D.C.
Intake valve diameter 44 mm
Exhaust valve diameter 38.5 mm
Valve lift
With 0 mm valve clearance Intake 11.20 mm
Exhaust 10.80 mm
Opening rocker arm - intake 0.10 to 0.15 mm 0.10 to 0.15 mm
Opening rocker arm - exhaust 0.10 to 0.15 mm 0.10 to 0.15 mm
Closing rocker arm - intake 0 to 0.05 mm 0 to 0.05 mm
Closing rocker arm - exhaust 0 to 0.05 mm 0 to 0.05 mm
Reference Adjusting clearance
(new belt)
Reset value
(used belt)
Belt tensioning when cold DDS 145±5 Hz (horizontal)
160±5 Hz (vertical)
100±5 Hz (horizontal)
100±5 Hz (vertical)
Limit value of the used belt
(when cold)
70 Hz
Exhaust system
Reference Technical specifications
Exhaust
Catalytic converter with lambda
sensor
Euro 3
Cylinder/Piston
Reference Standard value Service limit
Cylinder barrel
Max. bore ovality 0.03 mm
Max. bore taper 0.03 mm
Nominal diameter
Size group A
Size group B
Size group C
88 mm
88.000 to 88.010 mm
88.010 to 88.020 mm
88.020 to 88.030 mm
Piston-to-cylinder bore clearance
0.025 to 0.045 mm
Piston
Nominal diameter
Size group A
Size group B
Size group C
88 mm
87.965 to 87.975 mm
87.975 to 87.985 mm
87.985 to 87.995 mm
Connecting rod
Connecting-rod big-end
diameter
43.67 mm
Crankshaft - journal diameter
Ø 40.017 mm/Ø to
0.016 mm
Gudgeon pin–to-piston clearance
0.015 to 0.024 mm
Nominal diameters Ø 18 mm
Piston Ø 18 mm/0.020 to 0.015
Gudgeon pin Ø 18 mm/0 to 0.004
Gudgeon pin-to-connecting rod
clearance
0.028 to 0.041 mm
Cylinder compression
Standard
Minimum
Maximum permissible
difference
11 to 13 bar
min. 10 bar
max. 2 bar
Gearbox
Reference Standard value Service limit
Gearbox shafts
End float 0.05 to 0.020 mm
Selector drum
End float 0.10 to 0.040 mm
Gear selector fork
Selector fork end thickness 3.90 to 4.00 mm
