Torque settings
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_3_3.12.1.html[11/12/2015 18:40:11]
Stator wiring clamp bracket screw M5x0.8 5 4.5 5.5 LOCK 2 or TB1324
By-pass pump cap M15x1 17 15 19 LOCK 5 or TB1375B
Oil pump retaining screw M8x1.25 26 23 29
Oil pump retaining screw M6x1 10 9 11
Oil pump assembly screw M6x1 10 9 11
Special generator cover to stud screw
retaining screw
M6x1 13.5 12.5 14.5
Timing inspection cover screw M6x1 5 4.5 5.5
Note
For product specifications and symbols, refer to paragraph “Product specifications” (sect. 1 - 2).
