Torque settings
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_3_3.12.1.html[11/12/2015 18:40:11]
Screw securing subframe to frame M12x1.25
60 *
GREASE B
Nut on free play adjuster screw M25x1
100
*
GREASE B
Free play adjuster screw 0.6 GREASE B (on thread
only)
Screw securing LH side fuel tank pin to frame M6x1 10
Keyswitch cover cap nut M6x1 7
Keyswitch screw M6x1 Tighten down the
screw until head
fails – solid
threadlocker
Screw securing horn bracket to frame M6x1 10 LOCK 2
Screws securing fuel tank support plate to
subframe
M6x1 10
Screws securing subframe joining plate M8x1.25 22
screws securing subframe joining plate to rear
tile assembly
M6x1 8
Screws securing exhaust support plate to fuel
tank support plate
M6x1 5
Screw securing fuel tank to bracket on rear
subframe
M8x1.25 10 LOCK 1
Seat lock nut M22x1.5 3
Screw securing under seat storage
compartment
M5x0.8 5
Screw securing latch to subframe joining
bracket
M6x1 10
Screw securing wiring clips to RH rear subframe M4x0.7 2
Nut securing shock absorber upper mounting
clevis to subframe
M10x1.25
42
*
GREASE B
Exhaust valve actuator retaining screw M6x1 10
Oil cooler
Radiator fixing screw M6x1 10
Oil hose grommet retaining screw M6x1 10
Oil cooler nipple to cooler fastener M14x1.5 23 LOCK 1
Oil pipe union to cooler nipple fastener with O-
ring (TWIN SEAL)
M16x1.5
18
*
Engine oil
Oil pipe union to casing nipple fastener with O-
ring (TWIN SEAL)
M16x1.5
25 *
Engine oil
Thermistor fixing 10 LOCK 4
Air intake oil breather
Screws securing filter cover to airbox M5x0.8 5
Air filter retaining nut M6x1 6
Screws securing airbox to frame M6x1 10
Clamp securing oil breather valve hose to blow-
by valve
1.5
Clamp securing blow-by valve hose to airbox 1.5
screw securing coil to airbox M5x0.8 5
