Torque settings
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_3_3.12.1.html[11/12/2015 18:40:11]
Gearchange pedal pivot screw M8x1.25 24 LOCK 2
Fuel tank
Screw securing fuel tank support brackets to
fuel tank
M6x1 8
Screw securing fuel pipe guide to fuel tank M5x0.8 5
Screw securing flange to fuel tank M5x0.8 5 LOCK 2
Tank filler cap screw M5x0.8 3
Special screw (twin male thread) securing
flange to fuel tank
M5x0.8 5 LOCK 2
Flange cover retaining nut M5x0.8 3
Screw securing fuel tank side covers and
central cover to fuel filler cap
M5x0.8 2 LOCK 1
Screw securing front central clip cover to side
covers
M5x0.8 2 LOCK 1
Screws securing tank side covers to fuel tank
(lower side)
M5x0.8 2 LOCK 1
Screw securing cover to fuel tank (hidden) M5x0.8 2 LOCK 1
Exhaust
Screw securing exhaust crosspiece to support
under RH footrest
M6x1 5
Exhaust secondary to RH footrest bracket and
to tank/exhaust support bracket (LH) retaining
screw (796 ABS)
M6x1 5
(Horizontal/vertical) exhaust pipe clamp
fastener
M8x1.25 11
Screws securing silencers to subframe M6x1 10
Nut securing exhaust pipe flange to horizontal/
vertical cylinder head
1
st
nut initial tightening
2
nd
nut final tightening
1
st
nut final tightening
M8x1.25
6
24
24
1/8“ gas stainless steel plugs to exhaust pipes M10x1.25 25
Rear screw securing heat shield to silencer M6x1 10 LOCK 5
Screw securing silencer to silencer support on
subframe
M8x 1.25 22
Lambda sensor fixing 45
Front screw securing heat shield to silencer M6x1 8 LOCK 2
Screw securing heat shield to horizontal
exhaust
M6x1 8 LOCK 2
Exhaust valve cover screw M6x1 10
Exhaust secondary to tank/exhaust support
bracket (RH) retaining screw (796 ABS)
M6x1 10
Seat
Seat retaining screw M6x1 5
Frame
Nut securing subframe/frame to engine M12x1.25
60
*
GREASE B
