Torque settings
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_3_3.12.1.html[11/12/2015 18:40:11]
Rear suspension
Nut/screw securing shock absorber to mounting
clevis
M10x1.25
42
*
GREASE B
Screw securing shock absorber to swing arm M10x1.5
42 *
GREASE B
Front mudguard
Front mudguard retaining screw M6x1 5 LOCK 2
Front pipe grommet to mudguard fixing screw AF 3.5 0.35
Rear mudguard
Rear mudguard retaining screw M5x0.8 5 LOCK 2
Rear mudguard to brake pipe grommet
retaining screw (796 ABS)
M5x0.8 5 LOCK 2
Front wheel
Brake disc screw M8x1.25
25
*
LOCK 2
Front wheel nut M25x1.25
63
*
GREASE B
Rear wheel
Brake disc screw M8x1.25
25 *
LOCK 2
Rear sprocket nut M10x1.25 48 LOCK 2
Rear sprocket side wheel shaft retaining nut
(LH)
M33x1.5
156
*
GREASE B
Rim side wheel shaft retaining nut (RH) M38x1.5
176 *
GREASE B
screws securing driving pins M6x1 11 LOCK 2
Phonic wheel retaining screw (796 ABS) M5x0.8 5
Footrests and Levers
Screws securing front footrest brackets to
swingarm pivot
M12x1.25
55
*
GREASE B
Brake side
Brake lever pivot screw on RH footrest bracket M8x1.25 24 LOCK 2
Rear stop switch M6x1 5
Brake master cylinder pushrod retaining nut M6x1 7.5
Screw securing footrest bracket to engine (RH
side)
M10x1.5 36
Brake lever adjuster lock nut M6x1 2.3
Gearshift side
RH lock nut for gearchange linkage pivot M6x1 5 LOCK 2
Screw securing footrest bracket to engine (LH
side)
M10x1.5 36
LH lock nut for gearchange linkage pivot M6x1 5 LOCK 2
Screw/nut securing gearchange linkage pivot to
gearchange lever
M6x1 10
Screw securing gearchange lever to selector
claw
M6x1 10 LOCK 1
