Torque settings
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_3_3.12.1.html[11/12/2015 18:40:11]
Swinging arm pivot fastener M8x1.25
18 *
GREASE B
Chain tensioner eccentric fastener M12x1.25
31
*
GREASE B in the
sequence 1-2-1
Speed sensor wiring clamp fastener M4x0.7 1 LOCK 2
Grommet and lower hose guide to swinging arm
fastener (796 ABS)
M5x0.8 5
Upper chain slider fastener (796 ABS) M5x0.8 5
Chain guard to chain slider fastener 1.2 Australia version only
Rear brake
Brake hose couplings to master cylinder/calliper
fastener
M10x1 23
Screws securing rear brake fluid reservoir to
subframe
M6x1 2
Rear brake calliper screw M8x1.25
25
*
GREASE B
Rear brake master cylinder screw M6x1 10 LOCK 2
Screw securing rear brake hose guide to
swingarm
M5x0.8 5 LOCK 2
Hose guide on vertical cylinder head retaining
screw (796 ABS)
M6x1 10
Hose guide on crankcase fastener (796 ABS) M6x1
Hose guide on crankcase screw tightening (796
ABS)
AF 3.5 0.4
Number Plate Holder
Screw securing rear turn indicators to number
plate holder
M5x0.8 3 LOCK 2
screw securing upper to lower number plate
holder
M5x0.8 3.5
Tail light self-tapping screws 3
Bold/nut securing X plate to number plate
holder
M6x1 5 LOCK 2
Reflector nut M4x0.7 2
Number plate holder to protection fastener
(Australia version only)
M6x1 5 LOCK 2
Handlebar clutch lever
Handlebar clamp screw M8x1.25
25
*
GREASE B
Sequence 1-2-3-4-3
Clutch bleed valve M6x1 4
Clutch hose connector M10x1 23
clutch transmission unit screw M6x1 10 Sequence 1-2-3-1
Throttle twistgrip fixing screw M6x1 6 Sequence 1 (UP)-2-1
Clutch master cylinder screw M6x1 10 Sequence 1 (UP)-2-1
Throttle twistgrip housing screw M4x0.7 1.8
Throttle control cable retainer screw M10x1.25 4
Throttle control cable adjuster lock nut M6x1 2.5
