Torque settings
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_3_3.12.1.html[11/12/2015 18:40:11]
1
Nut securing clamp to steering head M10x1.25
45
*
Screws securing brake/clutch hose guide to
steering head
M6x1 10 LOCK 2
Screw securing headlight support plate to
steering head
M6x1 10 LOCK 2
Electric system
Screws securing coil to battery support M5x0.8 5
RH/LH handlebar switch screw M5x0.8 2.5
Screw securing battery lead to battery terminal M6x1 10
Nut securing contactor cable to starter motor M6x1 5 GREASE C
Nut securing battery leads/starter motor to
contactor
M6x1 4
Speed sensor retaining screw (796) M6x1 10
Nut securing battery support to airbox M5x0.8 5
Screws securing ECU to airbox M6x1 10
Screw securing earth cable to engine M6x1 10
Screw securing relay support to battery support M5x0.8 2
Screw securing battery support/airbox to frame M6x1 10
Oil pressure sensor wiring clamp screw M6x1 10 LOCK 2
ABS control unit to bracket retaining screw
(796 ABS)
M6x1 8±2
ABS sensor retaining screw (front + rear) (796
ABS)
M6x1 7 LOCK 2
ABS control unit bracket to airbox retaining
screw (796 ABS)
M6x1 10
ABS fuse bracket retaining screw (796 ABS) M5x0.8 7
Front brake
Screw securing front brake master cylinder to
handlebar
M6x1 10 Sequence 1 (UP)-2-1
Front/rear brake bleed valve M10x1 23
Front brake calliper retaining screws (RH + LH) M10x1.25
45
*
GREASE B
Front brake calliper initial tightening for bedding
(RH + LH)
M10x1.25 2 GREASE B
Coupling to brake master cylinder retaining
screw (796 ABS)
M10x1 23
ABS control unit to unions retaining screw (796
ABS)
M10x1 23
Brake calliper bleeder retainer (RH/LH) (796
ABS)
M6x1 4
Rear swingarm
Calliper mounting bracket peg fastener M12x1.25
33
*
LOCK 8
Lower grommet/chain slider to swinging arm
fastener
M5x0.8 5 LOCK 2
