-worn cylinder or piston rings.
Refit the spark plugs and reconnect the HT leads (1).
Fuel pressure test
Note
The on-screen icons used during this procedure are explained in a table at the end of this section.
In order to check the valve clearances, it is necessary to gain access to the four valve covers on the cylinder heads and
then remove the parts listed below.
Open the lock and simultaneously apply downward pressure in the area of the catch to release the pin; Pull the seat
backwards to release it from the front catches and remove it.
Remove the tank covers (Sect. 5 - 2, Removal of the fuel tank fairings).
Unscrew the side screw (1) securing tank to the frame and recover the washer (2).
Unscrew the rear screw (3) securing tank and recover the washer (4).
