Front wheel
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_7_1.38.1.html[11/12/2015 18:40:29]
Fit the front wheel between the fork legs, installing spacer (10) in-between wheel hub and right-hand fork bottom end,
and spacer (3) in-between wheel hub and left-hand fork bottom end.
Warning
Position the front wheel considering that arrow (E), marked on wheel left-hand side, indicates direction of rotation when
running.
Fit service tool no. 8000.70139 on the wheel shaft (8).
Drive the shaft (8) fully home into the wheel hub, inserting the locating peg of the service tool in the special notches at
the bottom end of the fork.
