Install the cartridge in its housing and tighten it to a torque of 11 Nm (Min. 10 Nm - Max. 12 Nm) (Sect. 3 - 3, Engine
torque settings).
Every two oil changes, clean the oil pickup gauze filter.
Remove the outer plug (5).
Unscrew the filter (7) and withdraw it from the crankcase.
Clean the filter with petrol and compressed air. Take care not to damage the gauze.
Replace the mesh filter (7), fit the seal (6) to the plug (5) and tighten to a torque of 42 Nm (Min. 38 Nm - Max. 46 Nm)
(Sect. 3 - 3,
Engine torque settings).
Remove the filler plug (2) and top-up with the specified oil type (Sect. 3 - 2, Fuel, lubricants and other fluids)
up to reaching the notch of MAX level on the sight glass.
Refit the filler cap (2). Run the engine at idle speed for a few minutes.
Check for oil leaks. Check that the oil pressure light on the instrument panel switches off a few seconds after the engine
starts. If not, switch off the engine and trace the fault.
After a few minutes, check that the oil level is the specified one; if necessary, restore the MAX level.
Refit all parts removed.
