Maintenance operations
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_4_3.17.1.html[11/12/2015 18:40:14]
With the valve in the rest position, slide a feeler gauge between the closing rocker arm and the closing shim to measure
the clearance:
Closing rocker arm
INTAKE: (B)
Adjusting clearance 0 to 0.05 mm
Checking clearance 0 to 0.05 mm
EXHAUST: (B)
Adjusting clearance 0 to 0.05 mm
Checking clearance 0 to 0.05 mm
