Maintenance operations
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_4_3.17.1.html[11/12/2015 18:40:14]
Important
If either of the pads is worn, both pads must be renewed as a set.
Change the brake pads as follows.
Remove the cotter pin (3) from the pad retaining pin.
Force the calliper pistons back into their bores by forcing the old brake pads apart.
Withdraw the pad retaining pins (4) from the outside.
Remove the clip (1) from between the two calliper halves.
Remove the worn pads (2).
Note
Change pads that have a shiny or “vitrified” appearance.
Insert the new pads and clip (1). Slide in the pad retaining pin (4) and secure it in position with the cotter pin (3).
Operate the brake lever repeatedly so that the pads are firmly bedded in against the disc by the force of the brake fluid.
Check that the level in the cylinder tank is not below the MIN mark. If necessary, top up as follows. Turn the handlebar so
that the reservoir is level.
Unscrew the two crosshead screws (6) and remove the reservoir cover (5).
Remove the inner membrane from the reservoir.
Top-up to the maximum level with the specified brake fluid (Sect. 3 - 2,
Fuel, lubricants and other fluids).
Refit all previously removed components.
