Chapter 21

| Class of Service Commands

Priority Commands (Layer 3 and 4)

– 532 –

Command Mode

Privileged Exec

Example

The following shows that the trust mode is set to CoS:

Console#show qos map trust-mode interface ethernet 1/5

Information of Eth 1/5

CoS Map Mode: CoS mode

Console#
