Chapter 3

| General Commands

– 86 –

Example

This example shows how to return to the Privileged Exec mode from the Global

Configuration mode, and then quit the CLI session:

Console(config)#exit

Console#exit

Press ENTER to start session

User Access Verification

Username:
