·234·
Operating manual
CNC 8055
CNC 8055i
13.
DIAGNOSIS
·T· MODEL
SOFT: V02.2X
Adjustments
Drive parameters that may be modified.
Axis parameters. Indicate the axis, the name of the parameter and the set separated by a period.
Example: X.CP1.0 Y.CP20.2 Z.SP1.1
Save and load the configurations of the oscilloscope
The system permits saving the current configuration into a file in ASCII format. To do that, set general
machine parameter STPFILE with the number to be assigned to the configuration file (the number
must be other than 0). The configuration file may be treated like any other program, sent out via DNC
or even edited.
When saving or loading a configuration, the CNC first checks if the file already exists in User RAM
and if not, it will look for it in the hard disk (KeyCF).
Several configurations may be saved in the configuration file. Each configuration must be assigned
a name of up to 40 characters.
The following softkeys are related to this feature.
Save To save the current configuration, press the [Save] softkey and enter the name
to save it with up to 40 characters. If there is a previously saved configuration with
the same name, it will ask whether it must be replaced or not.
Load To load a previously saved configuration, press the [Load] softkey and select it
from the list on the screen. If the configuration makes not sense (for example,
because the CNC does not have an axis that that configuration refers to), the CNC
will warn the user and it will only load the portion of the configuration read until
that error came up.
Delete To delete one of the saved configurations, press the [Delete] softkey, select it from
the list on the screen and press [ENTER].
Reset Pressing the [Reset] softkey resets the current configuration. There are neither
variables nor parameters selected and the rest of conditions (colors, trigger, etc.)
assume the values assigned by default.
Access to PLC resources
From the configuration screen, the system can access the PLC resources. The following syntax must
be used to access them:
• Marks: PLC.M1234
• Inputs: PLC.I25
• Outputs: PLC.O1
• Registers: PLC.R560
• Register Bit: PLC.B0R560
•Timers: PLC.T1
• Counters: PLC.C1
Access is also possible using the associated symbol.
Example: PLC.ENABLEX
An error will be issued when accessing a non-existent PLC resource.
