Operating manual.
CNC 8060
CNC 8065
6.
MANUAL (JOG) MODE. TOOL CALIBRATION
Automatic calibration with a probe and a canned cycle
·142·
(REF: 1807)
Tool calibration steps
To calibrate the length, follow these steps.
1 Select the tool and the offset to be calibrated. It is not necessary to insert the tool into
the spindle; the CNC carries out this operation if necessary.
2 Define the data defining the calibration. To calibrate a milling tool, use the horizontal
softkey menu to select the desired operation.
3 Press the [CYCLE START] key to start the calibration. The CNC calibrates the tool making
all the necessary movements; there is no need to manually approach the tool. If
necessary, the CNC makes the tool change.
4 After the calibration It updates the tool table data.
