Operating manual.
CNC 8060
CNC 8065
SETUP ASSISTANCE
22.
The circularity (roundness) test
·423·
(REF: 1807)
22.3.2 Softkey menus.
Horizontal softkey menu.
The horizontal softkey menu offers the following options.
Vertical softkey menu.
The vertical softkey menu offers the following options.
Softkey. Description.
Softkey "Simple". It captures the data of a full circle.
Softkey "Continuous". It captures data continuously.
Softkey "Stop". It stops the data capture. This softkey is shown when data
capture is running.
Softkey "Clear". It deletes the graphic representation. It may be done while the
capture is running; in that case, it goes on with the graphic
representation.
Softkey "Load". It loads a previously saved configuration.
Softkey "Save". It saves the configuration defined.
The "Stop" softkey only stops the data capture. It does not stop the movement of the axes. To stop the
movement of the axes, press the [STOP] key of the operator panel.
• Softkey "Validate".
It saves the values of the machine parameters in the tables of the CNC and/or
the drive accordingly.
When changing the values of the machine parameters, the changes are
effective immediately. However, these changes are maintained only during the
current session of the CNC; i.e. until the unit is turned off. On power-up, it
assumes the values stored in the tables.
• Softkey "Initialize".
It resets the window data to its default values.
