10.1 FCAS status.
The CNC will display the FCAS status on the top bar.
The FCAS status icons are only available when the SOFT FCAS software option is enabled. If it is not
enabled, the CNC will not display any icon.
Icon. Meaning.
Active feature.
Feature is disabled; the machine configuration is not loaded (xca file), the HD
graphics are not selected or the PLC has disabled this feature.
Blinking icon.
• The axes are close to the collision zone.
• CPU overload during collision detection calculations.
The variable VGCOLLISIONPERF indicates more details behind the cause of the
blinking.
