Operating manual.
CNC 8060
CNC 8065
EDISIMU MODE (EDITING AND SIMULATION)
8.
Interface description.
·157·
(REF: 1807)
8.1.1 Softkey menus.
Vertical softkey menu.
The vertical softkey menu always shows all the options associated with this operating mode
regardless of the active screen.
Softkey. Description.
Show more options on the softkey menu.
START (simulation)
Starts program simulation or resume it if it was interrupted. During simulation, the graphic
window will show the graphic representation of the program being simulated.
STOP (simulation)
Interrupt program simulation. Simulation will resume by pressing the START icon.
RESET (simulation)
Cancel program simulation. If an error occurs during simulation, reset eliminates the error
status and returns the simulation mode to its initial conditions.
Change the channel being displayed for editing and simulation. It does not affect the active
channel at the CNC.
(This icon will only be available when using channels).
Select the "single block" or "continuous" mode; either one may be selected even while
executing a program.
When "single block" mode is active (the icon will appear pressed), program simulation
will be interrupted at the end of each block. When the "automatic" mode is active, the
simulation will take place until the end of the program or up to the block selected as end
of simulation.
Analyze the program looking for syntax errors. The syntax check is not available for
programs written in 8055 CNC language.
If there are no errors, the bottom of the screen will display a message indicating that the
program is correct. If there are syntax errors, they will be shown at the bottom of the editing
window.
Offer an estimate of the total execution time at 100% of the programmed feedrate. The
result will appear at the statistics window.
(This icon is only available when the statistics window is displayed).
Configuring simulation options.
• Activate and cancel tool radius compensation.
• Conditional stop.
• Activate and deactivate the software travel limits.
• Block skip condition.
• Cancel the channel synchronization in the simulation.
